The commands to do the format is given below. Now we will proceed with the formatting of the hard drives /c2 and /d.
Since the /c2 is not automatically mounted, we will have to manually mount the drive by issuing the following command. We can check the directories within the NodeB by issuing vols Put the Node B in BackUp mode, by issuing the following command. Make sure that you see the command prompt $ Node B Commissioning This section explains in detail the steps mentioned in the previous section.įormat DUW Connect the serial cable to the LMT A port of DUW and run Tera Term software. 2.12.įormat DUW Install Basic package P7.1.6 Restart the Node B in the basic software Run Cabinet Equipment Wizard Run OAM Wizard Run Site Equipment wizard Run Iub_Scripts.mo Script Activate integration unlock Run HS_EUL_Parameters.mo Script Changing the RUW power to 60 Watts Installing the license key file Creating a Configuration Version.ģ. Without the license/ file or integration unlock the 5_ HS_EUL_Parameters.mo cannot be run successfully.Īny phone which is capable of the displaying the cell information (eg: TEMS, Phones with Netmon) 2. 1_Cabinet.xml 2_OAM.xml 3_Site_Equipment.xml 4_Iub_Scripts.mo 5_HS_EUL_Parameters.mo The license file/integration unlock is mandatory. Node B Scripts and License Total of 7 integration scripts are used during the RBS integration. Tera Term Version 4.61 Filezilla 3.2.2.1(FTP Client) or any other FTP client FileZilla Server Version 0.9.31(FTP Server) RBS Element Manager P7 Java1.6.0_14jre-6u14-windows-i586-s RBS 6000 Basic Software P7.1.6ġ.
Laptop with the below software installed 2. Preparation This section mentions the software and test tools required to do the RBS integration. Node B Commissioning and Integration 1 Preparation 1.1 Laptop with the below software installed 1.2 Cable and accessories 1.3 Node B Scripts and License 1.4 Test Phone 2 Node B Commissioning Process Summary 3 Node B Commissioning 3.1 Format DUW 3.2 Transfer the Basic software package to NodeB 3.3 Restart Node B with basic software 3.4 Run Cabinet Equipment Wizard 3.5 Run OAM Wizard 3.6 Run Site Equipment Configuration 3.7 Run Iub Transport script 3.8 Activating Integration Unlock 3.9 Run HS/EUL script 3.10 Changing the RUW power to 60 Watts 3.11 Installation of the License Key File 3.12 Creation of Configuration Version. ERICSSON Node B Commissioning and Integration
